NEW ABB 3BSC690074R1 S800 I/O Digital Output Module DO890 PR:C 11 V, 40 mA 16CH

Name: NEW ABB 3BSC690074R1 S800 I/O Digital Output Module DO890 PR:C 11 V, 40 mA 16CH
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: DO890
Price: 210.00 USD
Availability: InStock

Marka Adı:	ABB
Model Numarası:	DO890
Adedi:	1
fiyat:	Negotiations

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Oem

Sinyal spesifikasyonu:

11 V, 40 Ma

Kanal sayısı:

16 kanal

Sinyal Tipi:

Solenoid Sürücü

Tip:

Analog çıkış

Ambalaj bilgileri:

Yeni Orijinal Kutu

Ürün Tanımı

NEW ABB 3BSC690074R1 S800 I/O Digital Output Module DO890 PR:C 11 V, 40 mA 16CH

Description of DO890

Manufacturer : ABB
Product ID: 3BSC690074R1
Catalog Description : DO890 Digital Output 4x1 ch with Intrinsic Safety Interface Rated isol. 50V
I/O modules with intrinsic-safety interface
Number of channels: 4
Separate returns
Load 150-5000 ohms, 11V @ 40mA
Current source
Wire-fault detection
Short-circuit-proof
Shipping Weight: 1.3 Kg

General Information

Type	Digital Output
Signal specification	11 V, 40 mA
Article number	3BSC690074R1
Number of channels	4
Signal type	Solenoid driver
HART	No
SOE	No
Redundancy	No
High integrity	No
Intrinsic safety	Yes
Mechanics	S800

Detailed data

Isolation	Individually isolated, channel-to-channel and to circuit common ground
Output load	100 - 5000 Ω
Current limiting	Short circuit proof current limited output
Rated insulation voltage	50 V
Dielectric test voltage	500 V a.c.
Power dissipation	4.4 W
Current consumption +5 V Modulebus	Typ. 80 mA, Max. <150 mA
Current consumption +24 V external	Typ. 250 mA, Max. <360 mA
